Compact Tactical Manual PFD

MD3091

$497.40

Retail $716.45

The Mustang MD3091 is a compact life preserver that has been designed specifically for easy integration with body armor and tactical vests that use a MOLLE (Modular Lightweight Load-carrying Equipment) webbing system. The MD3091 can be inflated in seconds with a simple pull of the beaded handle. An oral inflation tube located on the left lobe provides backup inflation. SecureZip™ closure withstands rigorous activity and is easy to repack. A three point attachment system provides quick integration to a MOLLE vest and the low-profile design provides flotation capability for body armor wearers, with minimal bulk or interference. The MD3091 is a compact life preserver that provides durable flotation protection for law enforcement professionals operating in marine environments.

The MD3091 can alternatively be worn as a stand alone life preserver using the chest belt / crotch strap assembly MA3090.

Reliable Inflation

The inflatable cell achieves full inflation within seconds with a simple pull of the beaded handle. An oral inflation tube located on the left lobe provides backup inflation if necessary.

Quick Integration and easy Repacking

A three point attachment system provides quick integration to a MOLLE style vest and the low profile design provides flotation capability for body armor users, with minimum bulk or interference. Secure-ZIP™ closure withstands rigorous activity and is easy to repack.

In-water Performance

Tests with the life preserver attached to a typical body armor vest successfully demonstrated the ability of the life preserver to self-right and float the wearer.

Durable Protection

Designed for the Law Enforcement professional offering durable flotation protection for operators in marine environments.

Two Options for Wear

Can be attached to body armor vest or worn as a stand alone life preserver using the chest belt / crotch strap assembly MA3090.

Select Quantity
Select PFD Color
Re-Arm Kit F MA7113 (add $34.99)
Chest Belt Crotch Strap MA3090 (add $96.40)

Available Colors

MD3091 tactical Manual PFD black Black
MD3091 Special operations Manual PFD tan Coyote Tan

MD3091

MD3091 tactical Manual PFD black

MD3091 Special operations Manual PFD coyote tan

MD3091 compact Manual PFD inflated

Mustang Survival Gear brought to you by www.machovec.com
BERRY Compliant

Features

  • Front connection system allows for quick disconnect for those using releasable body armor systems
  • A three-point attachment system provides quick integration to MOLLE style vest
  • SecureZip™ closure withstands rigorous activity and is easy to repack
  • Repacking is easily accomplished with simple folding and Velcro® enclosures
  • Left side mounted outside pocket designed to accomodate two six inch chemlights, flashlight or other small equipment
  • Tab for attachment of a signal light
  • Can be attached to body armor vest or worn as a stand alone life preserver using the chest belt / crotch strap assembly MA3090
  • Inflatable cell achieves full inflation within seconds with a simple pull of the beaded handle, located on the right side of the cover
  • An oral inflation tube located on the left lobe provides backup inflation
  • Provides 35 lbs buoyancy
  • MA7113 re-arming kit F for the inflatable cell
  • Use only Mustang Survival re-arm kits. Use of other re-arm kits may result in improper operation or failure to operate and will void the product's warranty

US Patent 6832415

SKU: 062533115323 Black
SKU: 062533115347 Coyote Tan

MD3091 Size Chart

  Chest (inches) Weight (lbs) Chest (cm) Weight (kg)
Universal 30" - 52" 80lbs. or over 76 - 132 36 kg or over

Download Mustang Survival MD3091 Specifications Sheet

The MD3091 Data Sheet is a pdf file. If you are unable to open it you will need to download the latest FREE version of Adobe Acrobat Reader.

Get Adobe PDF reader FREE

Download Mustang Survival MD3091 User Manual

The MD3091 User Manual is a pdf file. If you are unable to open it you will need to download the latest FREE version of Adobe Acrobat Reader.

Get Adobe PDF reader FREE

Formula to Determine Buoyancy

If a man weighs 200 pounds on land, he only weighs 10 pounds in the water.

80% of the human body is water. Water in the body has no weight in the water.

200 pounds x 80% = 160 pounds
200 pounds – 160 pounds = 40 pounds

The human body is 15% fat, fat is lighter than water.

200 pounds x 15% = 30 pounds
40 pounds – 30 pounds = 10 pounds

A 200 pound person only weighs 10 pounds in the water.

A U.S.C.G. approved Type V vest is mandated to have 17.5 pounds of buoyancy.

If a man weighs 350 pounds on land, he only weighs:

80% of the human body is water. Water in the body has no weight in the water.

350 x 80% = 280 pounds
350 pounds – 280 pounds = 70 pounds

The human body is 15% fat, fat is lighter than water.

350 pounds x 15% = 52.5 pounds
70 pounds – 52.5 pounds = 17.5 pounds

A 350 pound person weighs 17.5 pounds in the water.

Type V PFD

In regards to using Work Vests or any other Life Jacket, the saying goes “It can only save your life if you’re wearing it.” Less obvious is what to expect upon entering the water once you take an unexpected fall. Depending on the height from which you fall, position of your body when entering the water, along with any currents present you may be kep under longer than you think. Type V Vests are required by United States Coast Guard to have a minimum buoyant force of 17 ½ pounds. This is adequate buoyancy to keep your head, neck and the top of your shoulders above the water. You will rise to the surface more quickly with more body fat and air pockets in your clothing. A lean and muscular person will rise more slowly to the surface.

A person of 200 lbs weighs 10 lbs in the water, 80% of a person’s weight is water which has no weight in the water, and about 15% is fat, which is lighter than water, consequently, the real weight of the person in water is about 10 pounds.

Having your Vest fit snugly is key to survival. Loose fitting or unbuckled Vests can slip over your head when falling feet first, allowing you to sink much further down. Hold on to your Vest as you enter the water just in case. Nothing is more important at that moment than getting your mouth above the top of the waves. Once in the water pull your Vest down to make sure all of the buoyancy is under the water. This will get your mouth and nose as high as possible. Most Vests have a strap that goes under your arms to keep your vest from riding up. If it is missing then replacement is recommended. Vests wear out over time and will lose some of their buoyancy. Here’s a quick way to check for the minimum buoyancy of 17 ½ pounds. Attach 20 pounds of steel weight to the Vest. Dumb bell weights work just fine. Twenty pounds of steel weight weighs approximately 17 ½ pounds in the water. If your Vest floats above or just below the surface, it still meets the minimum required buoyancy. If it sinks it should be replaced. The foam in your Vest will lose its buoyancy if it is compressed under weight or crammed in storage. It’s best to hang them or set them on a shelf when not in use.

Humans are land dwellers and need a little help in the water.
